Overview
The PoE powered device reference design demonstrates IEEE 802.3at 13W power delivery and 10/100 Ethernet communication using low cost standard cabling. The design can read 4 RTD temperature sensors and control 4 Triac’s connected to resistive headers.
The PCB is isolated into 3 areas. First is the PoE section isolated from the digital section via 48V to 5V transformer. The digital section is isolated from the Triac high voltage section using opt isolators.
Specifications
| CPU | |
|---|---|
| Name | ST Micro STM32H563 |
| Primary Core | Arm Cortex-M33 ( 250MHz ) |
| RAM | 640kByte |
| Flash | 1-2MByte |
| External Memory | 16MByte QSPI |
| Processor Longevity | 2034 |
| PoE | |
|---|---|
| PD controller | TPS23758 |
| Ethernet Phy | LAN8720 |
| Mag Jack | MOX-RJ45-132CT |
| Transformer | LDT1018-50R |
| Operating Systems | |
|---|---|
| RTOS | Azure RTOS |
| Physical / Environmental | |
|---|---|
| Dimensions (W x L) | |
| Industrial operating temperature | -40 to 85°C |
